Power Supply Converter
Product Overview
Certified Company ISO 14001:2015 & ISO 9001:2015
The DTPL DPSD220D Power Supply Converter is designed for industrial use, delivering efficient and reliable power to field equipment. Built with robust standards and high immunity to electromagnetic interference, it is ideal for demanding environments.
Explore the Design & Build
Reliable DC to AC Power Conversion for Field Equipment | High Efficiency & EMC Compliant
Technical Specifications
Key details including size, weight, materials, power, connectivity, and performance standards, ensuring reliability and compatibility.
| Product Name: Power Supply Converter | |
|---|---|
| Description: Hardware | |
| 1 | Make/Model: DTPL/ DPSD220D |
| 2 | Input Voltage Range: 200-240 VDC |
| 3 | Output Voltage Range: 200-240 VAC |
| 4 | Efficiency: 80% |
| 5 | Power Supply Unit: For Powering to field equipments (Industrial Use) |
| 6 | Operating Temperature: -10˚C to +55˚C |
| 7 | Size in MM: 203MM x 127MM x 177MM |
| 8 |
EMC Standards: IEC 61000-4-18: Damped Oscillatory 1 MHz & 100 kHz, Level 3 AC Voltage Dips & Interruption: Not applicable as power supply is 220V DC operated Electro Static Discharge (61000-4-2): Level 4 Magnetic Immunity Test (61000-4-8): Level 4 Electric Fast Transient (61000-4-4): Level 4 Ripple on DC Power Supply: IEC 61000-4-17 |
